Lowest Liquor Ratio, High Running Speed, Fast Dyeing System
For cotton 100% dyeing the lowest liquor ratio 1:5, running at high fabric speed (Max. speed can be 450M/min.)reduce cycle time to fast dyeing for economical energy & reduce cost, suitable for all kind of high quality cotton 100%, Rayon, wool with Lycra fabric ... etc.

Lowest tension, Full Flow Pipe Saturate Device
Use overflow Nozzle with Lowest pressure(Min.0.2 bar), reduce fabric tensionless, pilling & yarn sliding, cooperate with full flow pipe increase fabric saturate time for more even dyeing and crease free for high quality dyeing. Multi changeable Nozzle
with Multi gape suitable for fabric weight 50-500g/m².

Multi-function Fabric Vibration System
Special swing device for fabric storage(with wave type plate)for fabric and liquor separating and running smooth. Main reel and fabric Vibration system speed control by inverter, The fabric is deposited on the trough in an orderly fashion thereby increasing the capacity and reducing fabric tangling problems. Standard loading capacity 200kg/per tube. (For special heavy fabric can be option over width inside store chamber to reach 250kg/per tube)

Special Forming Collector & Fast Rinsing System
The forming natural into forming collector and separate with fabric, it can be protect fabric float to tangling and forming dirty problems. With level rining, overflow rining by time or Cooling water recycle rinsing/CCR(Option), reduce total cycle time(min.about5 hrs for dark color), reduce energy and lowest cost.

Easily Operation & Full Auto or Manual Control
Machine with full auto control by micro processor, it also can be auto dosing control(supply continoue dosing quality), with quickly fill, drain and Hot water tank (Option)to reduce total cycle time, Enhance production yield.

Advance, Compact Design
Machine operation height suitable for operator, Simple and safer operation, Space use very limited , Lowest maintenance, Lowest Energy, Lo west cost & High production capacity.
